Sheets

With forming, shearing, bending and other services available, Intsel Steel West streamlines your steel supply and even includes delivery. We help you reduce overhead with inventory management and storage options available in our own facilities. Don’t worry about coordinating transportation between the supplier and the processor, because we can deliver a finished product.

You no longer need to place multiple orders for your rebar, sheet steel, angles, beams, and more. With our network of suppliers across the western United States, we can delivery your entire order next day at a fixed rate.

Hot-Rolled Sheet Steel

Conforming to A1011, this commercial-quality, low-carbon, hot-rolled sheet steel can bend flat without cracking in any direction. Because of the normal mill oxide finish produced during the hot-rolling, this sheet is best used where surface finish is not critical.

Hot-Rolled, Pickled and Oiled Sheet Steel

Also conforming to A1011, the pickled and oiled finish allows for paint and enamel adhesion with a more uniform surface. Utilizing an acid-pickling process to remove oxides then oiling the surface, the sheets are better protected from rust and oxidation.

Hot-Rolled, High-Strength, Low-Alloy Sheet

Intsel Steel West provides Corten sheet, conforming to A606 for a higher minimum yield strength with two to four times the corrosion resistance the standard commercial-quality, hot-rolled sheet. Ideal for construction with a reduced weight requirement, hot-rolled HSLA sheet steel has a minimum yield strength of 50 ksi.

Cold-Rolled Sheet

Cold-rolled sheet steel is another commercial-quality, low-carbon steel that provides an even better surface quality than hot-rolled, pickled, and oiled sheets. It conforms to A366 and can be bent flat in any direction without cracking. This deoxidized surface easily accepts paint after cleaning and is lightly oiled to protect from rust.

Galvanized Sheet Steel

Galvanized sheet steel has a protective layer of zinc covering the commercial-quality, low-carbon steel. This zinc coating substantially increases the corrosion resistance when compared to uncoated hot-rolled sheets and can be formed without zinc flaking or peeling. Intsel Steel West carries various coating weights, spangle sizes, and ATM specifications to meet your needs

Cold Rolled Sheets High Strength Low Allow Hot Rolled Sheets Hot Rolled Pickled & Oiled Sheets Hot Rolled Steel Sheets
Type Thickness Size Dec.Equiv Weight Per Sq. Ft. Weight Per Sheet
Cold Rolled Sheets 18 Ga 48 x 120 in 0.0478 2.000 lb 80.0 lb
Cold Rolled Sheets 18 Ga 48 x 96 in 0.0478 2.000 lb 64.0 lb
Cold Rolled Sheets 18 Ga 36 x 120 in 0.0478 2.000 lb 60.0 lb
Cold Rolled Sheets 18 Ga 36 x 96 in 0.0478 2.000 lb 48.0 lb
Cold Rolled Sheets 16 Ga 60 x 120 in 0.0598 2.500 lb 125.0 lb
Cold Rolled Sheets 16 Ga 48 x 120 in 0.0598 2.500 lb 100.0 lb
Cold Rolled Sheets 16 Ga 48 x 96 in 0.0598 2.500 lb 80.0 lb
Cold Rolled Sheets 16 Ga 36 x 144 in 0.0598 2.500 lb 90.0 lb
Cold Rolled Sheets 16 Ga 36 x 120 in 0.0598 2.500 lb 75.0 lb
Cold Rolled Sheets 16 Ga 36 x 96 in 0.0598 2.500 lb 60.0 lb
Cold Rolled Sheets 14 Ga 60 x 120 in 0.0747 3.125 lb 156.3 lb
Cold Rolled Sheets 14 Ga 48 x 120 in 0.0747 3.125 lb 125.0 lb
Cold Rolled Sheets 14 Ga 48 x 96 in 0.0747 3.125 lb 100.0 lb
Cold Rolled Sheets 14 Ga 36 x 120 in 0.0747 3.125 lb 93.8 lb
Cold Rolled Sheets 14 Ga 36 x 96 in 0.0747 3.125 lb 75.0 lb
Cold Rolled Sheets 13 Ga 48 x 120 in 0.0897 3.750 lb 150.0 lb
Cold Rolled Sheets 13 Ga 48 x 96 in 0.0897 3.750 lb 120.0 lb
Cold Rolled Sheets 13 Ga 36 x 120 in 0.0897 3.750 lb 112.5 lb
Cold Rolled Sheets 13 Ga 36 x 96 in 0.0897 3.750 lb 90.0 lb
Cold Rolled Sheets 12 Ga 60 x 120 in 0.1046 4.375 lb 218.8 lb
Cold Rolled Sheets 12 Ga 48 x 120 in 0.1046 4.375 lb 175.0 lb
Cold Rolled Sheets 12 Ga 48 x 96 in 0.1046 4.375 lb 140.0 lb
Cold Rolled Sheets 12 Ga 36 x 120 in 0.1046 4.375 lb 131.3 lb
Cold Rolled Sheets 12 Ga 36 x 96 in 0.1046 4.375 lb 105.0 lb
Cold Rolled Sheets 11 Ga 60 x 120 in 0.1196 5.000 lb 250.0 lb
Cold Rolled Sheets 11 Ga 48 x 120 in 0.1196 5.000 lb 200.0 lb
Cold Rolled Sheets 11 Ga 48 x 96 in 0.1196 5.000 lb 160.0 lb
Cold Rolled Sheets 11 Ga 36 x 120 in 0.1196 5.000 lb 150.0 lb
Cold Rolled Sheets 11 Ga 36 x 96 in 0.1196 5.000 lb 120.0 lb
Cold Rolled Sheets 10 Ga 48 x 120 in 0.1345 7.66 lb 225.0 lb
Cold Rolled Sheets 10 Ga 48 x 96 in 0.1345 7.66 lb 180.0 lb
Cold Rolled Sheets 26 Ga 36 x 120 in 0.0164 0.750 lb 22.5 lb
Cold Rolled Sheets 26 Ga 36 x 96 in 0.0164 0.750 lb 18.0 lb
Cold Rolled Sheets 24 Ga 48 x 120 in 0.0239 1.000 lb 40.0 lb
Cold Rolled Sheets 24 Ga 48 x 96 in 0.0239 1.000 lb 32.0 lb
Cold Rolled Sheets 24 Ga 36 x 120 in 0.0239 1.000 lb 30.0 lb
Cold Rolled Sheets 24 Ga 36 x 96 in 0.0239 1.000 lb 24.0 lb
Cold Rolled Sheets 22 Ga 48 x 120 in 0.0299 1.250 lb 50.0 lb
Cold Rolled Sheets 22 Ga 48 x 96 in 0.0299 1.250 lb 40.0 lb
Cold Rolled Sheets 22 Ga 36 x 120 in 0.0299 1.250 lb 37.5 lb
Cold Rolled Sheets 22 Ga 36 x 96 in 0.0299 1.250 lb 30.0 lb
Cold Rolled Sheets 20 Ga 60 x 120 in 0.0359 1.500 lb 75.0 lb
Cold Rolled Sheets 20 Ga 48 x 144 in 0.0359 1.500 lb 72.0 lb
Cold Rolled Sheets 20 Ga 48 x 120 in 0.0359 1.500 lb 60.0 lb
Cold Rolled Sheets 20 Ga 48 x 96 in 0.0359 1.500 lb 48.0 lb
Cold Rolled Sheets 20 Ga 36 x 120 in 0.0359 1.500 lb 45.0 lb
Cold Rolled Sheets 20 Ga 36 x 96 in 0.0359 1.500 lb 36.0 lb
Cold Rolled Sheets 18 Ga 60 x 120 in 0.0478 2.000 lb 100.0 lb
High Strength Low Allow Hot Rolled Sheets 16 Ga 48 x 120 in 0.0598 2.500 lb 100.0 lb
High Strength Low Allow Hot Rolled Sheets 14 Ga 48 x 120 in 0.0747 3.125 lb 125.0 lb
High Strength Low Allow Hot Rolled Sheets 12 Ga 48 x 120 in 0.1046 4.375 lb 175.0 lb
High Strength Low Allow Hot Rolled Sheets 11 Ga 48 x 120 in 0.1196 5.000 lb 200.0 lb
High Strength Low Allow Hot Rolled Sheets 10 Ga 48 x 120 in 0.1345 5.625 lb 225.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 48 x 144 in 0.0598 2.500 lb 120.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 48 x 120 in 0.0598 2.500 lb 100.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 48 x 96 in 0.0598 2.500 lb 80.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 36 x 144 in 0.0598 2.500 lb 90.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 36 x 120 in 0.0598 2.500 lb 75.0 lb
Hot Rolled Pickled & Oiled Sheets 16 Ga 36 x 96 in 0.0598 2.500 lb 60.0 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 60 x 144 in 0.0747 3.125 lb 187.5 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 60 x 120 in 0.0747 3.125 lb 156.3 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 60 x 96 in 0.0747 3.125 lb 125.0 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 48 x 144 in 0.0747 3.125 lb 150.0 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 48 x 120 in 0.0747 3.125 lb 125.0 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 48 x 96 in 0.0747 3.125 lb 100.0 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 36 x 120 in 0.0747 3.125 lb 93.8 lb
Hot Rolled Pickled & Oiled Sheets 14 Ga 36 x 96 in 0.0747 3.125 lb 75.0 lb
Hot Rolled Pickled & Oiled Sheets 13 Ga 48 x 120 in 0.0897 3.750 lb 150.0 lb
Hot Rolled Pickled & Oiled Sheets 13 Ga 48 x 96 in 0.0897 3.750 lb 120.0 lb
Hot Rolled Pickled & Oiled Sheets 13 Ga 36 x 120 in 0.0897 3.750 lb 112.5 lb
Hot Rolled Pickled & Oiled Sheets 13 Ga 36 x 96 in 0.0897 3.750 lb 90.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 72 x 144 in 0.1046 4.375 lb 315.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 72 x 120 in 0.1046 4.375 lb 262.5 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 72 x 96 in 0.1046 4.375 lb 210.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 60 x 144 in 0.1046 4.375 lb 262.5 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 60 x 120 in 0.1046 4.375 lb 218.8 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 60 x 96 in 0.1046 4.375 lb 175.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 48 x 144 in 0.1046 4.375 lb 210.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 48 x 120 in 0.1046 4.375 lb 175.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 48 x 96 in 0.1046 4.375 lb 140.0 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 36 x 120 in 0.1046 4.375 lb 131.3 lb
Hot Rolled Pickled & Oiled Sheets 12 Ga 36 x 96 in 0.1046 4.375 lb 105.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 72 x 144 in 0.1196 5.000 lb 360.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 72 x 120 in 0.1196 5.000 lb 300.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 72 x 96 in 0.1196 5.000 lb 240.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 60 x 144 in 0.1196 5.000 lb 300.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 60 x 120 in 0.1196 5.000 lb 250.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 60 x 96 in 0.1196 5.000 lb 200.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 48 x 144 in 0.1196 5.000 lb 240.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 48 x 120 in 0.1196 5.000 lb 200.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 48 x 96 in 0.1196 5.000 lb 160.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 36 x 120 in 0.1196 5.000 lb 150.0 lb
Hot Rolled Pickled & Oiled Sheets 11 Ga 36 x 96 in 0.1196 5.000 lb 120.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 72 x 144 in 0.1345 5.625 lb 405.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 72 x 120 in 0.1345 5.625 lb 337.5 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 72 x 96 in 0.1345 5.625 lb 270.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 60 x 144 in 0.1345 5.625 lb 337.5 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 60 x 120 in 0.1345 5.625 lb 281.2 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 60 x 96 in 0.1345 5.625 lb 225.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 48 x 144 in 0.1345 5.625 lb 270.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 48 x 120 in 0.1345 5.625 lb 225.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 48 x 96 in 0.1345 5.625 lb 180.0 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 36 x 120 in 0.1345 5.625 lb 168.8 lb
Hot Rolled Pickled & Oiled Sheets 10 Ga 36 x 96 in 0.1345 5.625 lb 135.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 72 x 144 in 0.1793 7.50 lb 540.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 72 x 120 in 0.1793 7.50 lb 450.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 72 x 96 in 0.1793 7.50 lb 360.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 60 x 144 in 0.1793 7.50 lb 450.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 60 x 120 in 0.1793 7.50 lb 375.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 60 x 96 in 0.1793 7.50 lb 300.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 48 x 120 in 0.1793 7.50 lb 300.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 48 x 96 in 0.1793 7.50 lb 240.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 36 x 120 in 0.1793 7.50 lb 225.0 lb
Hot Rolled Pickled & Oiled Sheets 7 Ga 36 x 96 in 0.1793 7.50 lb 180.0 lb
Hot Rolled Pickled & Oiled Sheets 1/4 Ga 48 x 120 in 0.25 10.21 lb 408.4 lb
Hot Rolled Pickled & Oiled Sheets 1/4 Ga 48 x 96 in 0.25 10.21 lb 326.7 lb
Hot Rolled Pickled & Oiled Sheets 1/4 Ga 36 x 120 in 0.25 10.21 lb 306.3 lb
Hot Rolled Pickled & Oiled Sheets 1/4 Ga 36 x 96 in 0.25 10.21 lb 245.0 lb
Type Gauge Number Stock Sizes (In.) Weight Per Sq. Ft. Weight Per Sheet
Hot Rolled Steel Sheets 16 Ga. 48 x 96 2.5 80
Hot Rolled Steel Sheets 16 Ga. 48 x 120 2.5 100
Hot Rolled Steel Sheets 16 Ga. 48 x 144 2.5 120
Hot Rolled Steel Sheets 16 Ga. 60 x 96 2.5 100
Hot Rolled Steel Sheets 16 Ga. 60 x 120 2.5 125
Hot Rolled Steel Sheets 16 Ga. 60 x 144 2.5 150
Hot Rolled Steel Sheets 14 Ga. 48 x 96 3.125 100
Hot Rolled Steel Sheets 14 Ga. 48 x 120 3.125 125
Hot Rolled Steel Sheets 14 Ga. 48 x 144 3.125 150
Hot Rolled Steel Sheets 14 Ga. 60 x 96 3.125 125
Hot Rolled Steel Sheets 14 Ga. 60 x 120 3.125 156.3
Hot Rolled Steel Sheets 14 Ga. 60 x 144 3.125 187.5
Hot Rolled Steel Sheets 12 Ga. 48 x 96 4.375 140
Hot Rolled Steel Sheets 12 Ga. 48 x 120 4.375 175
Hot Rolled Steel Sheets 12 Ga. 48 x 144 4.375 210
Hot Rolled Steel Sheets 12 Ga. 60 x 96 4.375 175
Hot Rolled Steel Sheets 12 Ga. 60 x 120 4.375 218.8
Hot Rolled Steel Sheets 12 Ga. 60 x 144 4.375 262.5
Hot Rolled Steel Sheets 12 Ga. 72 x 120 4.375 262.5
Hot Rolled Steel Sheets 12 Ga. 72 x 144 4.375 315
Hot Rolled Steel Sheets 11 Ga. 48 x 96 5 160
Hot Rolled Steel Sheets 11 Ga. 48 x 120 5 200
Hot Rolled Steel Sheets 11 Ga. 48 x 144 5 240
Hot Rolled Steel Sheets 11 Ga. 60 x 96 5 200
Hot Rolled Steel Sheets 11 Ga. 60 x 120 5 250
Hot Rolled Steel Sheets 11 Ga. 60 x 144 5 300
Hot Rolled Steel Sheets 11 Ga. 72 x 120 5 300
Hot Rolled Steel Sheets 11 Ga. 72 x 144 5 360
Hot Rolled Steel Sheets 11 Ga. 72 x 240 5 600
Hot Rolled Steel Sheets 10 Ga. 48 x 96 5.625 180
Hot Rolled Steel Sheets 10 Ga. 48 x 120 5.625 225
Hot Rolled Steel Sheets 10 Ga. 48 x 144 5.625 270
Hot Rolled Steel Sheets 10 Ga. 60 x 96 5.625 225
Hot Rolled Steel Sheets 10 Ga. 60 x 120 5.625 281.3
Hot Rolled Steel Sheets 10 Ga. 60 x 144 5.625 337.5
Hot Rolled Steel Sheets 10 Ga. 72 x 120 5.625 337.5
Hot Rolled Steel Sheets 10 Ga. 72 x 144 5.625 405
Hot Rolled Steel Sheets 10 Ga. 72 x 240 5.625 675

Sheet Steel in CO, CA, UT and beyond

Get all your steel from sheets to bars to beams in a single purchase order from Intsel Steel West. We take care of the entire project at once then ship it next day wherever you need it. With facilities across the western US from Colorado, California, Utah, Arizona, Nevada, New Mexico, Montana, Idaho, and Nebraska, we can be exactly where you need us, when you need us. Call us today for a quote.
